Lone Star Aviation Ruggedized – Series Inverters:
The following series of DC-AC pure sine-wave inverters convert 12 or 24 Volts DC input voltage to an output power of 200 up to 3500 watts to either 120 VAC or 230VAC. This inverter series is UL458 safety approved, FCC Class A approved, Compliance to EN55022 EN61000-3-2,3, EN60950-1 and e-13 72/245/EEC, 95/54/EC Class A. The inverters include dual (North America) (GFCI) AC receptacles for consumer safety and compatibility to most ac plugs and or ac equipment. If a Universal, Schuko, Australian or UK output AC receptacles is needed contact the factory for its availability, lead time may vary by part number.
Circuit Protections include: AC GFCI safety, overload, over-temperature, temp controlled fans, short-circuit, reverse-polarity, low battery, isolated circuit, under & over voltage protections. A low power saving mode is also an additional feature to conserve energy.
Military COTS design parameters can be added as an option for a more ruggedized protection to pcb, electronic components, component support and mounting hardware. Options for MIL-A 46146 silicone, MIL-I-46058C conformal coatings, vibration, shock support, humidity protection will further extend the life of product in a ruggedized environment.
Pure sine wave output (THD<3%
Input & output fully isolated
Thermostatically controlled cooling fans
12/24 VDC input and 110 VAC output
Protections: Overload/Short circuit/Over temp, Low power saving mode
High efficiency, high frequency switching mode design
High output current surge
Two GFCI AC receptacles
Aircraft experimental, Military COM centers, vehicles, iPad-iPhone charging stations,
Airport COM Center, Airport Vehicles, Mining Vehicles, Marine, Sub-station,
Telecommunication Com racks, Field ac applications, solar power racks, Emergency backup,
Computers, EFB’s, Tablets, Printers, SAT COM, SAT Radios, Ruggedized applications.
The listed inverters, parts, components as well as high current models may not be in stock status, anticipated delivery for non-stock models could be 1, 2 weeks or sooner.
DO160G TESTS conducted: Humidity, Audio, EMI, Magnetic Effect, Temperature, and Dust. Additional DO160G TEST is available and will be quoted to a specific Section and Category. Company level TESTING will include a TEST REPORT with pictures, graphs, equipment set-up procedures and TEST results.
